Frequency Response

2 Hz - 200 kHz (+0 dB /-3 dB)

Crosstalk

-125 dB

Power Consumption (Idle)

30 W

Power Consumption (Full Power Standby)

27 W

Power Consumption (Low Power Standby)

5.5 W

Shipping Weight

54 lbs / 25 kg

Dimensions (width x height x depth)

18.95 x 5.53 x 17.66 in.

48.1 x 14 x 44.9 cm.

Analog Input Impedance

22 kΩ

Analog Input Impedance

22 kΩ

Maximum Gain (Line Level)

13.5 dB

Phono Input Gain

40 dB / 54 dB / 60 dB / 66 dB

Phono Input Capacitance

0 / 100 pF / 470 pF

Phono Input Resistance

10 Ω / 100 Ω / 1 kΩ / 47 kΩ

Output Impedance

50 Ω

Signal-to-Noise Ratio (Analog Preamplifier)

125 dB

Dynamic Range (Digital Input, Fixed Output)

125 dB

Total Harmonic Distortion + Noise

0.0003%

Intermodulation Distortion

0.00006%
