S/N Ratio (full scale @ 40dB gain)

110dBr

S/N Ratio (full scale @ 66dB gain)

88dBr

Frequency Response

20Hz - 20kHz ±0.5dB

Crosstalk @ 1kHz

-100dB

Output impedance

50Ω

THD (20Hz - 20kHz)

0.001%

Intermodulation distortion

0.009%

Input overload @ 40dB gain

58mV RMS @ 1kHz

Input overload @ 66dB gain

3.0mV RMS @ 1kHz

Shipping Weight

7.0 lbs / 3.1 kg

Dimensions (width x height x depth)

7.0 x 3.0 x 11.0 in.
17.8 x 7.6 x 28.0 cm.

‍

‍
